Description
Details
AC voltage range 110-130V,
DC voltage range 115-135V,
High power factor 0.98,
Total harmonic distortion <20%, high energy efficiency,
Operating frequency >40 kHz,
Lead type,
Filled inside special black compound-jelly,
Wide operating temperature range from -15 to +50 C,
Suitable for use in emergency lighting,
Safe switch off of defective lamps,
Automatic re-start after lamp change,
Protection against lamp open circult (lamp disconnected),
Ingress protection ip65.
| Order no. | Lamp Wattage | Specification | Circuit Power | Current at 120V / 50Hz | PF at 120V 50/60Hz | ta (degree Celsius) | tc (degree Celsius) |
| 856102-E1F15P | 1x15W | 1x15W 110V-130V 0/50/60Hz | 15W | 0.13A | 0.97 | -20 to +50 | 70 |
| 856102-E1F18P | 1x18W | 1x18W 110V-130V 0/50/60Hz | 18W | 0.15A | 0.97 | -20 to +50 | 70 |
| 856102-E1F30P | 1x30W | 1x30W 110V-130V 0/50/60Hz | 30W | 0.26A | 0.97 | -20 to +50 | 70 |
| 856102-E1F36P | 1x36W | 1x36W 110V-130V 0/50/60Hz | 36W | 0.31A | 0.97 | -20 to +50 | 70 |
| 856102-E1F58P | 1x58W | 1x58W 110V-130V 0/50/60Hz | 58W | 0.50A | 0.97 | -20 to +50 | 70 |
| 856102-E1F70P | 1x70W | 1x70W 110V-130V 0/50/60Hz | 70W | 0.60A | 0.97 | -20 to +50 | 70 |
| 856102-E2F15P | 2x15W | 2x15W 110V-130V 0/50/60Hz | 30W | 0.26A | 0.97 | -20 to +50 | 70 |
| 856102-E2F18P | 2x18W | 2x18W 110V-130V 0/50/60Hz | 36W | 0.30A | 0.97 | -20 to +50 | 70 |
| 856102-E2F30P | 2x30W | 2x30W 110V-130V 0/50/60Hz | 60W | 0.52A | 0.97 | -20 to +50 | 70 |
| 856102-E2F36P | 2x36W | 2x36W 110V-130V 0/50/60Hz | 72W | 0.62A | 0.97 | -20 to +50 | 70 |
| 856102-E2F58P | 2x58W | 2x58W 110V-130V 0/50/60Hz | 116W | 1.01A | 0.97 | -20 to +50 | 70 |
| 856102-E1F17P | 1x17W | 1x17W 110V-130V 0/50/60Hz | 17W | 0.15A | 0.97 | -20 to +50 | 70 |
| 856102-E1F25P | 1x25W | 1x25W 110V-130V 0/50/60Hz | 25W | 0.21A | 0.97 | -20 to +50 | 70 |
| 856102-E1F32P | 1x32W | 1x32W 110V-130V 0/50/60Hz | 32W | 0.27A | 0.97 | -20 to +50 | 70 |
| 856102-E2F17P | 2x17W | 2x17W 110V-130V 0/50/60Hz | 34W | 0.29A | 0.97 | -20 to +50 | 70 |
| 856102-E2F25P | 2x25W | 2x25W 110V-130V 0/50/60Hz | 50W | 0.43A | 0.97 | -20 to +50 | 70 |
| 856102-E2F32P | 2x32W | 2x32W 110V-130V 0/50/60Hz | 64W | 0.55A | 0.97 | -20 to +50 | 70 |
| Product dimension: 240x43x30mm, Packing dimension: 27x26x20cm/carton. total 25 pcs in carton | |||||||
